Onshore Energy Security Program - Five year Work Plan

Appendix two

Summary of proposed and possible airborne electromagnetic surveys in the OESP

Regions under consideration for airborne electromagnetic data acquisition during the OESP. Possible surveys are shown as areas outlined by thin lines within heavier rectangles.

Figure A2 Regions under consideration for airborne electromagnetic data acquisition during the OESP. Possible surveys are shown as areas outlined by thin lines

[back to top]

Proposed and possible airborne electromagnetic surveys are listed below in order of level of scoping to date (note: not all surveys will be funded in the OESP; prioritisation is yet to be finalised).

Paterson Province, WA (acquisition commenced September 2007)

Target mineral systems:	Unconformity-related U
Example:	Kintyre U deposit
Geology:	Graphitic units in Rudall Complex basement Overlying Coolbro Sandstone Major structures facilitating fluid flow Proximity to Archaean (Pilbara) granite in northwest of survey area
Comments:	Survey excludes Rudall River National Park

[back to top]

Frome Embayment, SA (proposed; scoping well advanced)

Target mineral systems:	Palaeochannel U, Sandstone U
Example:	Beverley, 4 Mile, Honeymoon
Geology:	Namba Formation (Cz), Eyre Formation (Cz) Eromanga Basin (K) U-rich Mesoproterozoic granite
Comments:	Brownfields – AEM to provide regional context to outline palaeochannels and K-Cz faulting

[back to top]

Pine Creek, NT (proposed; scoping well advanced)

Target mineral systems:	Unconformity-related U
Example:	Ranger, Jabiluka
Geology:	Archaean granitic domes Graphitic units in Palaeoproterozoic rocks Overlying Kombolgie Sandstone
Comments:	Aim to map thickness of Kombolgie Fm as well as identify graphitic schists in basement; brownfields

[back to top]

Birrindudu/Tanami, NT (possible; proposal being scoped)

Target mineral systems:	Unconformity-related U
Geology:	Archaean - Proterozoic granite in domes Carbonaceous units in Tanami Group basement Overlying sandstone units in Birrindudu Group
Comments:	Greenfields, but known minor U prospects

[back to top]

Northern Eyre peninsula, SA (possible; proposal being scoped)

Target mineral systems:	Unconformity-related U
Geology:	Mesoproterozoic Hiltaba Suite granites Carbonaceous units in the Hutchison Group Overlying Pandurra Formation, Corunna Conglomerate and Blue Range Beds
Comments:	Greenfields but some minor U prospects known

[back to top]

Capricorn Orogen / Northern Yilgarn margin, WA (proposal being scoped)

Target mineral systems:	Unconformity-related U
Geology:	Abundant U-rich, low Ca, Archaean granite Adjacent-overlying Palaeoproterozoic sediments (Yerrida and Earaheedy Basins ) Major structures in the Archaean basement
Comments:	Greenfields project but has several of key ingredients of unconformity-related U

[back to top]

Westmoreland, Qld (proposal being scoped)

Target mineral systems:	Mafic intrusive-related U/unconformity-related U
Geology:	Murphy Tectonic Ridge/Cliffdale Volcanics (source of U?) Overlying Westmoreland Conglomerate
Comments:	Brownfields – numerous small U deposits

[back to top]

Mount Isa– eastern margin, Qld (proposal being scoped)

Target mineral systems:	Sandstone U - Cainozoic palaeochannels
Geology:	High-U Mesoproterozoic Williams Batholith granites
Comments:	Greenfields region but numerous generally small U deposits in Mt Isa Inlier

[back to top]

Ngalia – Amadeus Basin region, NT (proposal being scoped)

Target mineral systems:	Cainozoic palaeochannels
Geology:	U-rich granite in Arunta Complex Poorly known palaeochannels with >200 m of fill and some evidence of lignite
Comments:	Greenfields region

[back to top]

Southern Yilgarn margin, WA (proposal being scoped)

Target mineral systems:	Palaeochannel U
Example:	Mulga Rock
Geology:	Abundant U-rich, low Ca, Archaean granite to north/northwest Palaeochannels containing lignite which has fixed U
